Intelligent peripheral pump (25QB)
Intelligent peripheral pump (25QB)
WORKING CONDITION
Max. liquid temperature | +100℃ |
Max. ambient temperature | +40℃ |
Insulation | Class F |
Waterproof rating | IP44 |
Duty cycle | S1 |
Input voltage | Single phase, 220V, 50/60Hz |
MODEL INSTRUCTION
|
25QB: Peripheral pump |
180: Power (W) |
S: Adaptive fucntion |
PRODUCT FEATURE
1, Adaptive function
Automatically identify the pipe pressure
Automatically regulate the starting pressure
2, Dual control system (pressure&flow switch)
Support stepless pressure regulation for pump with 0-100m head
3, Water shortage protection
4, Auto-start when tap water re-comes
5, Frequent start&stop protection
6, Thermal protection
7, Timing function (optional)
8, Electrophoresis, corrosion&rust resistant
9, Plug and play
10, Intelligent learning and memory function
TECHNICAL PARAMETER (n=2850r/min)
Model | Power | Power | Max. flow | Max. flow | Max. head | Max. suction | Inlet&Outlet |
25QB-180(S) | 180 | 0.2 | 2.0 | 33 | 25 | 7 | 1"×1" |
25QB-280(S) | 280 | 0.4 | 2.0 | 33 | 30 | 7 | 1"×1" |
25QB-380(S) | 380 | 0.5 | 2.1 | 35 | 35 | 7 | 1"×1" |
